HD WIFI wall mount 21.5 Touch Screen Kiosk 178x178 Viewing Angle High Contrast Ratio
· Place of Origin: Guangdong, China (Mainland)
· Brand Name: ADW
· Model Number: ADW-AD2105
· Type: TFT
· Application: Indoor
· Panel Size: 21.5 Inch
· Max Resolution: 1920x1080
· Viewing Angle: 178x178
· Pixel Pitch: 0.76125x0.76125mm
· Color: 8Bit,16.7M
· Contrast Ratio: 4000:1
· Brightness: 350cd/m2
· Response Time: 5ms
· Input Voltage: AC110V-240V,50/60HZ
· surface: anti-glare
· panel backlight: CCFL
· control method: RS232 control
· consummtion: 180W
· signal support: DVI/HDMI/VGA/AV/YPBPR
· Color system: PAL/NTSC/SECAM
· Operation System: Android
· Menu language: Multiple languages
Specifications for 21.5inch Touch Screen Digital Signage
| System | CPU | | | | RK3288 quad-core Cortex-A17 @1.8G GPU Mali T764 |
| RAM | | | | 2GB/4GB (optional) |
| Internal memory | | | | 8GB/16GB/32GB(optional) | | | | | | | | | |
| Operation system | | | | Android 9.0 | | | | | | | | | |
| | | Touch screen | | | | 10 point capacitive touch(optional) | | | | | | | | | |
| Display | Panel | | | | 21.5" | | | | | | | | | |
| Resolution | | | | 1920*1080 | | | | | | | | | |
| Contrast ratio | | | | 1000:1 | | | | | | | | | |
| Luminance | | | | 250cd/m2 | | | | | | | | | |
| Aspect Ratio | | | | 16:9 | | | | | | | | | |
| Network | WiFi | | | | 802.11b/g/n | | | | | | | | | |
| Buletooth | | | | Bluetooth 4.0 | | | | | | | | | |
| Ethernet | | | | 10M/100MEthernet | | | | | | | | | |
| Interface | USB x 1 | | | | USB host *2 | | | | | | | | | |
| Mini USB | | | | Mini USB OTG | | | | | | | | | |
| Power jack | | | | DC power 12V input | | | | | | | | | |
| Card slot | | | | SD card | Maximum support for 32G | | | | | | | | |
| HDMI | | | | Support HDMI outputDefault (optional) | | | | | | | | | |
| RJ45 | | | | Ethernet port |
| speaker | | | | 3W * 8Ω * 3 | | | | | | | | | |
| Earphone | | | | 3.5mm earphone | | | | | | | | | |
| Key | Key | | | | No,single key, five key (optional) |
| Media play | Video format | | | | MPEG-1,MPEG-2,MPEG-4,H.263,H.264,H.265,VC1,VP8,RV etc.,support up to 3840x2160 | | | | | | | | | |
| Audio format | | | | MP3,WMA,WAV, APE, FLAC, AAC, OGG,M4A,3GPP etc. | | | | | | | | | |
| Text processing | | | | EPUB, WORD, EXCEL, POWERPOINT, PDF, | | | | | | | | | |
| E-book | | | | PDF,TXT,CHM,DOC,EXCEL,EPUB,RTF,FB2 | | | | | | | | | |
| Photo | | | | JPG,BMP,PNG | | | | | | | | | |
system management | APK installation | | | | APK installation |
| Root permissions | | | | Original ecological Android system, open root permissions, customizable development | | | | | | | | | |
| Remote control | | | | Real-time remote monitoring, system crash self recovery, 7*24 hours unattended | | | | | | | | | |
| OTA upgrade | | | | Support OTA remote upgrades | | | | | | | | | |
| | Camera | | | | Pre 200W/500W (default none , optional) | | | | | | | | | |
| Language | | | | Multi-language | | | | | | | | | |
| Accessories | Adapter | | | | Adapter,12V/3A | | | | | | | | | |
| User manual | | | | yes | | | | | | | | | |
| Warranty card | | | | yes | | | | | | | | | |
| Touch Screen Digital Signage |
